*[2] 9600 Baud For choose FC Bus
in 8-30
*[3] 19200 Baud For choose
Modbus in 8-30
[4] 38400 Baud
8-33 FC Port Parity
*[0] Even Parity, 1 Stop Bit
[1] Odd Parity, 1 Stop Bit
[2] No Parity, 1 Stop Bit
[3] No Parity, 2 Stop Bits
8-35 Minimum Response Delay
0.001–0.5 * 0.010 s
8-36 Max Response Delay
0.100–10.00 s * 5.000 s
8-4* FC MC protocol set
8-43 FC Port PCD Read Configuration
*[0] None Expressionlimit
[1] [1500] Operation Hours
[2] [1501] Running Hours
[3] [1502] kWh Counter
[4] [1600] Control Word
[5] [1601] Reference [Unit]
[6] [1602] Reference %
[7] [1603] Status Word
[8] [1605] Main Actual Value [%]
[9] [1609] Custom Readout
[10] [1610] Power [kW]
[11] [1611] Power [hp]
[12] [1612] Motor Voltage
[13] [1613] Frequency
[14] [1614] Motor Current
[15] [1615] Frequency [%]
[16] [1618] Motor Thermal
[17] [1630] DC Link Voltage
[18] [1634] Heatsink Temp.
[19] [1635] Inverter Thermal
[20] [1638] SL Controller State
[21] [1650] External Reference
[22] [1651] Pulse Reference
[23] [1652] Feedback [Unit]
[24] [1660] Digital Input 18,19,27,33
[25] [1661] Digtial Input 29
[26] [1662] Analog Input 53 (V)
[27] [1663] Analog Input 53 (mA)
[28] [1664] Analog Input 60
[29] [1665] Analog Output 42 [mA]
[30] [1668] Freq. Input 33 [Hz]
[31] [1671] Relay Output [bin]
[32] [1672] Counter A
[33] [1673] Counter B
[34] [1690] Alarm Word
[35] [1692] Warning Word
[36] [1694] Ext. Status Word
8-5* Digital/Bus
8-50 Coasting Select
[0] DigitalInput
[1] Bus
[2] LogicAnd
*[3] LogicOr
8-51 Quick Stop Select
See par. 8-50 * [3] LogicOr
8-52 DC Brake Select
See par. 8-50 *[3] LogicOr
8-53 Start Select
See par. 8-50 *[3] LogicOr
8-54 Reversing Select
See par. 8-50 *[3] LogicOr
8-55 Set-up Select
See par. 8-50 *[3] LogicOr
8-56 Preset Reference Select
See par. 8-50 * [3] LogicOr
8-8* Bus Communication
Diagnostics
8-80 Bus Message Count
0–0 N/A * 0 N/A
8-81 Bus Error Count
0–0 N/A * 0 N/A
8-82 Slave Messages Rcvd
0–0 N/A * 0 N/A
8-83 Slave Error Count
0–0 N/A * 0 N/A
8-9* Bus Jog / Feedback
8-94 Bus feedback 1
0x8000–0x7FFF * 0
13-** Smart Logic
13-0* SLC Settings
13-00 SL Controller Mode
*[0] Off
[1] On
13-01 Start Event
[0] False
[1] True
[2] Running
[3] InRange
[4] OnReference
[7] OutOfCurrentRange
[8] BelowILow
[9] AboveIHigh
[16] ThermalWarning
[17] MainOutOfRange
[18] Reversing
[19] Warning
[20] Alarm_Trip
[21] Alarm_TripLock
[22-25] Comparator 0-3
[26-29] LogicRule0-3
[33] DigitalInput_18
[34] DigitalInput_19
[35] DigitalInput_27
[36] DigitalInput_29
[38] DigitalInput_33
*[39] StartCommand
[40] DriveStopped
13-02 Stop Event
See par. 13-01 * [40] DriveStopped
13-03 Reset SLC
*[0] Do not reset
[1] Reset SLC
13-1* Comparators
13-10 Comparator Operand
*[0] Disabled
[1] Reference
[2] Feedback
[3] MotorSpeed
[4] MotorCurrent
[6] MotorPower
[7] MotorVoltage
[8] DCLinkVoltage
[12] AnalogInput53
[13] AnalogInput60
[18] PulseInput33
[20] AlarmNumber
[30] CounterA
[31] CounterB
13-11 Comparator Operator
[0] Less Than
*[1] Approximately equals
[2] Greater Than
13-12 Comparator Value
-9,999–9,999 * 0.0
13-2* Timers
13-20 SL Controller Timer
0.0–3,600 s * 0.0 s
13-4* Logic Rules
13-40 Logic Rule Boolean 1
See par. 13-01 *[0] False
[30] - [32] SL Timeout 0-2
13-41 Logic Rule Operator 1
*[0] Disabled
[1] And
[2] Or
[3] And not
[4] Or not
[5] Not and
[6] Not or
[7] Not and not
[8] Not or not
13-42 Logic Rule Boolean 2
See par. 13-40 * [0] False
13-43 Logic Rule Operator 2
See par. 13-41 *[0] Disabled
13-44 Logic Rule Boolean 3
See par. 13-40 * [0] False
13-5* States
13-51 SL Controller Event
See par. 13-40 *[0] False
13-52 SL Controller Action
*[0] Disabled
[1] NoAction
[2] SelectSetup1
[3] SelectSetup2
[10-17] SelectPresetRef0-7
[18] SelectRamp1
[19] SelectRamp2
[22] Run
[23] RunReverse
[24] Stop
[25] Qstop
[26] DCstop
[27] Coast
[28] FreezeOutput
[29] StartTimer0
[30] StartTimer1
[31] StartTimer2
[32] Set Digital Output A Low
[33] Set Digital Output B Low
[38] Set Digital Output A High
[39] Set Digital Output B High
[60] ResetCounterA
[61] ResetCounterB
14-** Special Functions
14-0* Inverter Switching
14-01 Switching Frequency
[0] 2 kHz
*[1] 4 kHz
[2] 8 kHz
[4] 16 kHz not available for M5
14-03 Overmodulation
[0] Off
*[1] On
14-1* Line power monitoring
14-12 Function at line imbalance
*[0] Trip
[1] Warning
[2] Disabled
14-2* Trip Reset
14-20 Reset Mode
*[0] Manual reset
[1-9] AutoReset 1-9
[10] AutoReset 10
[11] AutoReset 15
[12] AutoReset 20
[13] Infinite auto reset
[14] Reset at power-up
14-21 Automatic Restart Time
0–600s * 10s
14-22 Operation Mode
*[0] Normal Operation
[2] Initialization
14-26 Action At Inverter Fault
*[0] Trip
[1] Warning
14-4* Energy Optimizing
14-41 AEO Minimum Magnetization
40–75% * 66%
15-** Drive Information
15-0* Operating Data
15-00 Operating Days
15-01 Running Hours
15-02 kWh Counter
15-03 Power-ups
15-04 Overtemps
15-05 Over Volts
15-06 Reset kWh Counter
*[0] Do not reset
[1] Reset counter
15-07 Reset Running Hours Counter
*[0] Do not reset
[1] Reset counter
15-3* Fault Log
15-30 Fault Log: Error Code
15-4* Drive Identification
15-40 FC Type
15-41 Power Section
15-42 Voltage
15-43 Software Version
15-46 Adj. Freq. Drive Order. No
15-48 ID No
15-51 Adj. Freq. Drive Serial No
16-** Data Readouts 16-0* General
Status
16-00 Control Word
0–0XFFFF
16-01 Reference [Unit]
-4,999–4,999 * 0.000
16-02 Reference %
-200.0–200.0% * 0.0%
16-03 Status Word
0–0XFFFF
16-05 Main Actual Value [%]
-200.0–200.0% * 0.0%
16-09 Custom Readout
Dep. on par. 0-31, 0-32 and 4-14
16-1* Motor Status
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage [V]
16-13 Frequency [Hz]
16-14 Motor Current [A]
16-15 Frequency [%]
16-18 Motor Thermal [%]
16-3* Drive Status
16-30 DC Link Voltage
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-36 Inv.Nom. Current
16-37 Inv. Max. Current
16-38 SL Controller State
16-5* Ref./Feedb.
16-50 External Reference
16-51 Pulse Reference
16-52 Feedback [Unit]
Table 1.10
Quick Guide
VLT
®
Micro Drive Quick Guide
MG02B722 - VLT
®
is a registered Danfoss trademark 1-13
1 1
