Power (HP [kW]) Torque (Nm)
Frame
Size
1 x 200–240V 3 x 200–240V 3 x 380–480V Line Motor DC connection/Brake Control Terminals Ground Relay
M1
0.24–1 [0.18–
0.75]
0.34–1 [0.25–
0.75]
0.5–1 [0.37–
0.75]
1.4 0.7
Spade
1)
0.15 3 0.5
M2 2 [1.5] 2 [1.5] 2–3 [1.5–2.2] 1.4 0.7
Spade
1)
0.15 3 0.5
M3 3 [2.2] 3–5 [2.2–3.7] 4–10 [3.0–7.5] 1.4 0.7
Spade
1)
0.15 3 0.5
M4
15–20 [11.0–
15.0]
1.3 1.3 1.3 0.15 3 0.5
M5
25–30 [18.5–
22.0]
1.3 1.3 1.3 0.15 3 0.5
1)
Spade connectors (0.25 in [6.3 mm] Faston plugs)
Table 1.5 Tightening of Terminals
