Chapter 3
Summary of Parameters
This chapter summarizes all 10 of the parameter groups. For complete descriptions of i
iindividual parameters refer to the english manual.
No.No.
No.No.
No.
ParameterParameter
ParameterParameter
Parameter
FunctionFunction
FunctionFunction
Function
ParameterParameter
ParameterParameter
Parameter
FactoryFactory
FactoryFactory
Factory
NameName
NameName
Name
ExplanationExplanation
ExplanationExplanation
Explanation
VV
VV
V
aluealue
aluealue
alue
SettingSetting
SettingSetting
Setting
00 Master Speed Master frequency d00:Master frequency input d00
Frequency source select determined by the digital
Setting control panel
d01:Master frequency input
determined by t he analog
signal (DC 0 to +10 V)
d02:Master frequency input
determined by the analog
signal (DC 4 to 20 mA)
01 Operation Operation d00:Operating instructions d00
Command command determined by the digital
Source source select control panel
d01:Operating instructions
determined by the external
terminal connections,
keypad STOP key effective
d02:Operating instructions
determined by the external
terminal connections, keypad
STOP key not effective
02 Motor stop Motor stop d00:RAMP stop d00
method method select d01:Coasting to stop
03 V/F Curve Max output freq. d50.0 - d400.0 Hz d60.0
04 Setting Max voltage freq. d10.0 - d255.0 V d60.0
05 (13 & 14) Max output volt d2.0 - d255.0 V d220.
06 Mid-point freq. d0.1 - d400. Hz d1.50
07 Mid-point volt d2.0 - d255.0 V d12.0
08 Min output freq. d0.1 - d20.0 Hz d1.50
09 Min output volt d2.0 - d50.0 V d12.0
10 Accel/Decel Acceleration time 1 d0.1 - d600. s d10.0
11 Time Setting Deceleration time 1 d0.1 - d600. s d10.0
12 Acceleration time 2 d0.1 - d600. s d10.0
