8-52 DC Brake Select
Option: Function:
Select control of the DC brake via the terminals
(digital input) and/or via the eldbus.
NOTICE
When parameter 1-10 Motor Construction is
set to [1] PM non-salient SPM, only selection
[0] Digital input is available.
[0] Digital
input
Activates a start command via a digital input.
[1] Bus Activates a start command via the serial communi-
cation port or eldbus option.
[2] Logic
AND
Activates a start command via the eldbus/serial
communication port, and also via 1 of the digital
inputs.
[3] Logic OR Activates a start command via the eldbus/serial
communication port, or via 1 of the digital inputs.
8-53 Start Select
Option: Function:
Select control of the frequency converter start
function via the terminals (digital input) and/or
via the eldbus.
[0] Digital
input
Activates a start command via a digital input.
[1] Bus Activates a start command via the serial
communication port or eldbus option.
[2] Logic
AND
Activates a start command via the eldbus/
serial communication port and also via 1 of the
digital inputs.
[3] * Logic OR Activates a start command via the eldbus/
serial communication port or via 1 of the digital
inputs.
8-54 Reversing Select
Option: Function:
[0] Digital
input
Select control of the frequency converter reverse
function via the terminals (digital input) and/or
via the eldbus.
[1] Bus Activates the reverse command via the serial
communication port or eldbus option.
[2] Logic AND Activates the reverse command via the eldbus/
serial communication port and also via 1 of the
digital inputs.
[3] Logic OR Activates the reverse command via the eldbus/
serial communication port or via 1 of the digital
inputs.
8-55 Set-up Select
Option: Function:
Select control of the frequency converter set-up
selection via the terminals (digital input) and/or
via the eldbus.
[0] Digital
input
Activates the set-up selection via a digital input.
[1] Bus Activates the set-up selection via the serial
communication port or eldbus option.
[2] Logic
AND
Activates the set-up selection via the eldbus/
serial communication port and via 1 of the
digital inputs.
[3] * Logic OR Activates the set-up selection via the eldbus/
serial communication port or via 1 of the digital
inputs.
8-56 Preset Reference Select
Option: Function:
Select control of the preset reference selection
via the terminals (digital input) and/or via the
eldbus.
[0] Digital
input
Activates preset reference selection via a digital
input.
[1] Bus Activates preset reference selection via the
serial communication port or eldbus option.
[2] Logic AND Activates preset reference selection via the
eldbus/serial communication port and via 1 of
the digital inputs.
[3] * Logic OR Activates the preset reference selection via the
eldbus/serial communication port or via 1 of
the digital inputs.
8-90 Bus Jog 1 Speed
Range: Function:
100 RPM* [ 0 - par. 4-13
RPM]
Enter the jog speed. Activate this
xed jog speed via the serial port
or eldbus option.
8-91 Bus Jog 2 Speed
Range: Function:
200 RPM* [ 0 - par. 4-13
RPM]
Enter the jog speed. Activate this
xed jog speed via the serial port
or eldbus option.
Parameters
VLT
®
PROFIBUS DP MCA 101
38 Danfoss A/S © 01/2016 All rights reserved. MG37G202
6
6
