Object name
Class
Instance
Attribute
1 = Multiply power by 100 to get W
2 = Power (kW)
3 = Multiply power by 10 to get kW
% Power factor
103
122
100
Average rms voltage across all 3 phases
103
123
100
Phase 1 current
103
124
100
Phase 2 current
103
125
100
Phase 3 current
103
126
100
Phase 1 voltage
103
127
100
Phase 2 voltage
103
128
100
Phase 3 voltage
103
129
100
Parameter list minor version
103
130
100
Parameter list major version
103
131
100
Digital input state
For all inputs, 0 = open, 1 = closed (short-circuited)
Start/stop input = 01h, reset = 04h, programmable input A = 08h, programmable input B = 10h
103
132
100
N O T I C E
The reset input is normally closed by default. If parameter 7-9 Reset/Enable Logic is set to normally open, the reported state is
inverted (0 = closed, 1 = open).
7.2.2.3 Class 104 Objects (Read Only)
Class 104d (0x68) allows extended information to be read from the soft starter.
Object name
Class
Instance
Attribute
Major software version - User interface
104
101
100
Minor software version - User interface
104
102
100
Major software version - Motor control
104
103
100
Minor software version - Motor control
104
104
100
Major software version - Remote LCP (if installed)
104
105
100
Minor software version - Remote LCP (if installed)
104
106
100
Major software version - Expansion card (if installed)
104
107
100
Minor software version -. Expansion card (if installed)
104
108
100
7.2.3 Supported Services for Vendor-specific Objects
This section describes the operational instructions to carry out acyclic services on class objects 100, 101, 103, and 104.
AN353423548483en-000101 / 130R094522 | Danfoss A/S © 2020.12
Messaging
EtherNet/IP Card
Installation Guide
