22
www.Daniel.com
MODEL 700 CONTROL VALVE
NOTICE
Flush lines to remove welding bead, pipe scale, etc.
NOTICE
Install the valve in a horizontal line with the cylinder head at the top.
Figure 2-1: Valve orientation
WARNING
EQUIPMENT HAZARD
Never use this equipment for any purpose other than its intended use.
Failure to comply may result in death, serious personal injury and/or property damage.
Operating conditions and specifications User manual
November 2020 P/N 3-9008-553
