MODEL 700 CONTROL VALVE
Table 2-5: Dimensions for the control valve
A B
Class 150 Class 300 Class 600 Class 150-300 Class 600
Valve
Size
inches mm inches mm inches mm inches mm inches mm
2 10-1/4 260 10-1/2 267 11-1/2 292 9-5/8 244 9-3/4 248
3 11 279 13-1/8 333 14 356 10-3/8 264 11-1/4 286
4 13 330 14-1/2 368 17 432 10-7/8 276 11-1/2 292
6 17 432 17-7/8 454 22 559 13-3/8 340 13-5/8 346
8 22-1/4 565 23-1/4 590 26 660 17-1/4 438 17-3/4 451
10 26-1/2 673 27-7/8 708 31 787 17-5/8 448 20-5/8 524
12 30-7/8 784 33-5/8 854 36-1/2 927 20-7/8 530 22-7/8 581
16 41-3/8 1051 43-1/2 1105 46 1168 30 762 30 762
