ENGLISH
19
 
Part# Description
1 Damper (x2)
2 Upper Smoker Cabinet Assembly (x1)
3 Back Handle (x1)
4 Cooking Grid (x3)
5 Cooking Grid Support (x6)
6 Door Latch Assembly (x1)
7 Door Handle (x1)
8 Door Silcon Gasket (x1)
9 Heat Indicator (x1)
10 Door Assembly (x1)
11 Wood Chip Box Lid (x1)
12 Wood Chip Box Assembly (x1)
13 Control Knob (x1)
14 Lower Smoker Cabinet Assembly (x1)
14.1 Control Panel Assembly
(included HVR, Control Knob Bezel & Igniter) (x1)
14.2 Control Panel (x1)
14.3 HVR Assembly (x1)
14.4 Igniter (x1)
14.5 Control Knob Bezel (x1)
15 Water Pan (x1)
16 Water Pan Support (x1)
17 Gas Cyclinder Retainer Bracker (x1)
18 Right Rear Leg Assembly (x1)
19 Support Panel (x2)
20 Left Rear Leg Assembly (x1)
21 Left Front Leg (x1)
22 Right Front Leg (x1)
23 Back Support Tube (x1)
24 Burner Chamber Assembly (x1)
24.1 Burner Chamber (x1)
24.2 Main Burner (x1)
24.3 Wood Chips Burner Assembly
(included Electrode & Electric Wire) (x1)
24.4 Cross-Fire Tube (x1)
25 Grease Tray Assembly (x1)
26 Door Grease Shield (x1)
Part# Description
A ¼–20x⅝" Screw (x4)
B ¼–20x½" Screw (x16)
C #10–24x½" Screw (x32)
D #10–24 Lock Nut (x2)
E M5 Locking Washer (x2)
F Zip-tie (x1)
G #8-32 Self-tapping Screw (x5)
H Spare Hardware
NOTE: Due to ongoing product development, parts are subject to change without
notice. Contact Customer Care if parts are missing when assembling the unit.
