Operation, continued
Menu structure and navigation. Step up/down to jump through menues, end enter to select
the parameter to read or change.
Step Actions Display
Hibernate mode shows the actual room temperature. After 3 minutes without
any activity on the keys, the controllers exits any any menu and shows this.
Use up/down to select any below menu
24
CooL
Cooling set-point parameter
Press enter 2 sec. and change the value
followed by enter to save.
C25
Heat
Heater set-point parameter
Press enter 2 sec. and change the value
followed by enter to save.
H05
Err
Operation error list. See complete list
at section “Error list” on page 14
Press enter 2 sec. and change the read-
ings to see if more error are present
simultaneously.
E05
Test
Over ride test. This will run a series of
component tests. See complete list
at section “Steps in test program” on
page 14
Press enter 2 sec. to start the test. The
test steps will increase by one after 60
seconds or be changed manually with
up/down. The test will auto disable
after 30 minutes, if not manually left
before, with enter key
In hibernate mode press and hold the Enter key for 5 seconds to toggle Celsius and
Fahrenheit unit in all temperature readings.
Navigating menu
Toggle Celsius to
Fahrenheit readings
