Installation, continued
Please incorporate the following imperative requirements when installing the electrical
connections:
• Installation should always be in accordance with national wiring regulations.
• AC external supply should be protected with an external disconnecting device that has
a contact separation of at least 3 mm. This external AC supply must also be over current
protected. The disconnecting device must always be labeled with rated voltage as well as
rated current.
• The unit’s earth connections must always be connected to the enclosures ground.
• All cables in a permanent installation, must be installed and secured properly to
prevent any damage to equipment and/or humans. Secure all cables with cable ties or
appropriate cable fasteners made for this purpose.
After unit installation, the electrical connections should be completed, following below
requirements:
1. The power and/or additional connections should be routed, secured, and connected to
appropriate sources. The Air Conditioner is either delivered with:
A. 5 ft. cable with
Black lead: +48V
Red Lead: -48V
B. 6 ft. cable with
Black lead: +48V
Blue Lead: -48V.
2. If the power supply cord needs to be extended, always use at minimum, the same AWG.
3. All power supply connections should be secured with an external disconnection device.
Also ensure the connections are over current protected. The fuse specication for the
referring unit type/size can be found in the model overview table on page 5.
4. Connect any accessory needed according the specication to be found in the chapter for
external connections on page 11, Fig. 7.
Electrical
requirements
Electrical
connections
