darda C2S - Splitters; Hydraulic Oil

3 Technical Data
6 IM Hydraulic Stone and Concrete Splitter, Version 1.0 04/2010
3 Technical Data
3.1 Splitters
Type
Splitting
head
Required
borehole
diameter
Minimum
borehole
depth
Splitting
distance
Theoretic
splitting
force
mm mm mm kN/tonne
C2S N 32-33 270 9 3490/355
C4S N 35-36 430 10-40 4524/461
C4S WL 35-38 540 14 3267/333
C4S WLL 35-38 700 14 3267/333
C9 N 45-48 410 18-44 2995/305
C9 L 45-48 580 18-40 2995/305
C9 LL 48-50 1080 18-40 2995/305
C10S N 41-43 630 18-45 4948/504
C12 W 45-48 550 24-56 4849/494
C12 N 45-48 610 20-50 6061/618
C12 L 45-48 680 15-35 8082/824
Type
Splitting
head
Effective split-
ting force
Weight
Length of
splitting
cylinder
Length of
splitting
head
kN/tonne kg mm mm
C2S N 1913/195 18 745 140
C4S N 2256/230 22 995 250
C4S WL 1864/190 23 1145 400
C4S WLL 1864/190 24 1255 510
C9 N 1962/200 22 1020 230
C9 L 1962/200 23 1190 400
C9 LL 1962/200 28 1690 900
C10S N 2551/260 32 1400 380
C12 W 3150/321 31 1250 340
C12 N 3507/358 31 1290 380
C12 L 4048/413 32 1380 450
3.2 Hydraulic oil
Normal conditions Cold regions
ISO VG 22 ISO VG 10
