19 / 47
(6) Install the cabinet: Hang the cabinet on the mounting bracket and fix it on both sides with the screws
removed in step 2. There are three outlet holes on the cabinet (as shown below), and one hole is selected
as the cable in and out according to the needs of the site.
Note: When installing on the floor, the wall drilling height should ensure that the cabinet feet
can touch the ground, and then adjust the foot support with a wrench.
Top outlet hole
Left-side outlet hole
Bottom outlet hole
