c. Connect the B-terminal of BAT4 of
Cabinet-1 and the B1 terminal of BAT7 of
Cabinet-2 to the negative terminal of Bus
Terminal by wire harness (label
5619100023601), and connect it to the
negative side of inverter BAT side from
the output side of Bus Terminal.
d. Use the wire harness (label with
CAN1, length 4000mm) to connect
the CAN2 communication interface
of Cabinet-1 BAT4 to the CAN1
communication interface of BAT5 of
Cabinet-2
