This document describes the DL-300E reporting event codes when using the SIA format (format 14). The following codes
are programmable and are sent when the 100's digit is programmed as the event code. The 10's and 1's digit are then sent
as a zone identifier.
PROGRAMMED 100's DIGIT SIA CODE DEFINITION
0 PA PANIC ALARM
1 FA FIRE ALARM
2 PA PANIC ALARM
3 BA BURGLARY ALARM
4 GA GAS ALARM
5 KA HEAT ALARM
6 WA WATER ALARM
7 QA EMERGENCY ALARM
8 SA SPRINKLER ALARM
9 UA UNTYPED ALARM
10 HA HOLDUP ALARM
11 MA MEDICAL ALARM
12 ZA FREEZE ALARM
13 TA TAMPER ALARM
14 RP PERIODIC TEST
15 RESERVED
The following event codes are fixed but must be enabled by programming a 1 in the corresponding location.;
REPORTING EVENT SIA CODE LOCATION
TAMPER TA 336
AUTOTEST RP 340
CHECKSUM ERROR YF 344
OPENING OP 348
CLOSING CL 350
CANCEL OC 354
AC LOSS AT 356
LOW BATTERY YT 360
RESTORE CODE *R 364
BYPASS CODE *B 368
BYPASS RESTORE *U 368 / 364
TROUBLE CODE *T 372
TROUBLE RESTORE *R 372 / 364
AC RESTORE AR 376
BATTERY RESTORE YR 376
FAIL TO CLOSE CI 592
EARLY OPENING OK 588
DOWNLOAD COMPLETE RS 596
The character transmitted in this slot will be the first character in the SIA code from the top list for the event being reported.
If a "1" is programmed in location 374, and a Burglary Alarm (B A) restores, a B R will be transmitted. If a " 1" is
programmed in location 372, and a Fire Alarm (F A) zone goes into Trouble, an (FT) will be transmitted.
