Data Aire DAP III Instructions

Data Aire, Inc. DAP
TM
III BACnet Integration Instructions
Engineering Document - 600-000-460
Page 9 of 13
Object Name Instance
No. BV
Object Description Present-
Value
Writeable
Custom Alarm 2
(Optional)
39 The optional alarm input 2 is
programmed to Custom alarm #2 and the
alarm signal is active
No
Custom Alarm 3
(Optional)
40 The optional alarm input 3 is
programmed to Custom alarm #3 and the
alarm signal is active
No
Custom Alarm 4
(Optional)
41 The optional alarm input 4 is
programmed to Custom alarm #4 and the
alarm signal is active
No
Humidification Inhibited
(optional)
42 The optional inputs are programmed to
Humidification inhibited and the input
signal is active
No
Reheat Inhibited
(Optional)
43 The optional inputs are programmed to
Reheat inhibited and the input signal is
active
No
Reheat And Humid. Inhibited
(Optional)
44 The optional inputs are programmed to
Reheat and Humidification inhibited and
the input signal is active
No
Low Discharge Air Temperature
Alarm
(Optional)
45 The Discharge Air temperature drops
below the low discharge temperature
setting limit. An optional Discharge Air
temperature sensor required
No
Manual Override 46 Manual override switches are on; unit
operates in the manual control mode.
No
High Condensate water level
(Optional)
47 High condensate water level switch of
the optional condensate pump closes.
This is a standard alarm on ceiling units.
No
Unit In Standby, All Functions
Held Off Alarm (Optional)
48 The optional alarm input 1 is
programmed to Unit in standby, all
functions held off and the alarm signal is
active. Unit is put to standby mode.
No
Cooling Inhibit 1001 The Cooling stages will be inhibited
when this point is on.
Yes-
Enumerated
(0,1)
Heating Inhibit 1002 The Heating stages will be inhibited
when this point is on
Yes-
Enumerated
(0,1)
Humidification Inhibit 1003 The Humidification function will be
inhibited if this point is on
Yes-
Enumerated
(0,1)
Dehumidification Inhibit 1004 The dehumidification function will be
inhibited if this point is on.
Yes-
Enumerated
(0,1)
Blower Inhibit 1005 The blower(s) will stop if this point is
on. In a normal circumstance, this point
should be off at all time
Yes-
Enumerated
(0,1)
