Dap4 Wiring Connections - continued
Digital Outputs
Pin ID
Connector
Unit TB
System Blower
NO1
J12-2
TB1-4
Compressor 1
NO2
J12-3
TB1-5
Compressor 2
NO3
J12-4
TB1-6
Cooling 3rd Stage
NO4
J13-2
TB2-37
Cooling 4th Stage
NO5
J13-3
TB2-38
Humidifier
NO6
J13-4
TB1-8
Status Contact (function is selectable)
C7
J14-1
TB1-9
NO7
J14-2
TB1-10
Condenser Aux or Glycol Valve
NO8
J15-1
TB2-47
C8
J15-2
TB2-46
Reheat 1
NO9
J16-2
TB1-7
Reheat 2
NO10
J16-3
TB1-20
Reheat 3
NO11
J16-4
TB1-21
Alarm 3 (function is selectable)
NO12
J17-1
TB1-45
C12
J17-2
TB1-43
NC-12
J17-3
TB1-44
Alarm 4 (function is selectable)
Light Sensor on gPOD model
NO13
J18-1
TB2-50
C13
J18-2
TB2-48
NO13
J18-3
TB2-49
Alarm 1 (function is selectable, by default
output will turn on due to any alarm)
NO14
J21-1
TB1-13
C14
J21-2
TB1-11
NC14
J21-3
TB1-12
Alarm 2 (function is selectable)
NO15
J21-4
TB1-42
C15
J21-5
TB1-40
NC15
J21-6
TB1-41
Energy Saver On
NO16
J22-2
TB1-19
Humidifier Drain (Autoflush)
NO17
J22-3
TB2-39
CO2 Valve (gPOD model only)
NO18
J22-4
