DataCard CD800 Quick Install Guide

10 CD800 Card Printer
CD800 Card Printer Quick Install Guide
6. Install the Card Printer Driver (Optional)
If you plan to use the XPS Card Printer Driver, refer to
your printer’s Driver Guide for installation instructions
using either a USB or a network connection.
7. Print a Test Card (Optional)
Use the printer’s LCD panel to print a test card:
2
4
5
3
6
1
7

DataCard CD800 Specifications

General

Print Resolution	300 dpi
Weight	12 lbs (5.4 kg)
Power Requirements	100-240 VAC, 50/60 Hz
Print Technology	Dye-sublimation
Card Capacity	100 cards (standard hopper)
Connectivity	USB
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Compatibility	Windows
Card Thickness	0.020" - 0.040" (0.51 mm - 1.02 mm)
