SP Series Install e-Guide
6 Use the following settings:
7 When the settings are correct, click OK to save settings and close the dialog box.
Setting a serial port for Windows Me or 98
1 From the Start menu, choose Settings and then Control Panel.
2 From the control panel, open System.
3 On the System Properties dialog box, click the Device Manager tab.
Setting Value
Baud rate 9600
Data bits 8
Parity None
Stop bits 1
Flow control None
