59
SP Series Install e-Guide
8 Use the following settings:
9 When the settings are correct, click OK to save settings and close the dialog box.
Setting the serial port on Windows NT
1 From the Start menu, choose Settings and then Control Panel.
2 From the Control Panel, open Ports.
3 From the Ports dialog box, choose the port, such as COM1 or COM2.
4 Click the Settings button to display the port settings.
— If the PC has more than one serial port, make sure you view the settings for the serial port to which the
smart card is attached.
5 Use the following settings:
Setting Value
Bits per second 9600
Data bits 8
Parity None
Stop bits 1
Flow control None
Setting Value
Baud rate 9600
Data bits 8
Parity None
