SP Series Info Central: Setup
Each bitmap has a sample image, to help you understand the orientation when you open it. See "Setting a
customized blocking area" for the steps to follow when changing one of these bitmaps.
If the side of the card for which you want customized blocking includes more than one blocking area, you need to
create all blocking areas in the bitmap file. Datacard ID Works® ID software allows you to specify the following
LandscapeBlockTopcoatBack.bmp 1013 by 638 pixels
3.37 by 2.125 inches
85.6 by 53.98 mm.
Blocks topcoat on the back of a
card with landscape orientation.
PortraitBlockPrintFront.bmp 638 by 1013 pixels
2.125 by 3.37 inches
53.98 by 85.6 mm.
Blocks printing on the front of a
card with portrait orientation.
PortraitBlockPrintBack.bmp 638 by 1013 pixels
2.125 by 3.37 inches
53.98 by 85.6 mm.
Blocks printing on the back of a
card with portrait orientation.
PortraitBlockTopcoatFront.bmp 638 by 1013 pixels
2.125 by 3.37 inches
53.98 by 85.6 mm.
Blocks topcoat on the front of a
card with portrait orientation.
PortraitBlockTopcoatBack.bmp 638 by 1013 pixels
2.125 by 3.37 inches
53.98 by 85.6 mm.
Blocks topcoat on the back of a
card with portrait orientation.
File name Dimensions (Height by Width) Comments
