Datalogic DL-Axist - USB Dock Connection

Connections
184 DL-Axist™
USB Dock Connection
The single dock can be connected to the host computer by means of a
standard micro USB cable.
Once the host computer has been turned on, insert the DL-Axist into
the dock.
NOTE
Connection through the cable complies to USB 2.0
standard.
NOTE
The actual data transfer speed can be appreciably lower
than the maximum theoretical speed.
Host
Computer
DL-Axist
USB cable
Single Slot
Dock
Power Supply
