GENERAL VIEW
Figure 3 - F734-E Series
Terminals Overview
B
E
D
C
A
F
Key:
A)
Laser beam output window
B) Multi-function
LED
C)
Reset key (protected)
D)
Cradle communications window
E)
Battery charger contacts
F) Antenna
