MAINTENANCE
4
3- Replace the batter
pack, making sure the
batteries are inserted
in the right direction as
indicated within the
case.
-
+
-
+
CAUTION
Before inserting the battery pack into the
terminal, ensure the battery polarity matches
with the one indicated within the case.
CONTACTS
Figure 19 Figure 20
CAUTION
When inserting the battery pack, first slide it
towards the springs compressing them until
the contacts at the other end are cleared (see
Figure 18). Then, push downwards to insert
the pack (see Figure 19). Be very careful not
to damage the contacts when pushing
downwards.
4- Close the battery cover and tighten the screws
WARNING
Do not incinerate, disassemble, short
terminals or expose to high temperature. Risk
of fire, explosion. Use specified charger only.
Risk of explosion if the battery is replaced by
an incorrect type. Dispose of the batteries as
required by the relevant laws in force.
25
