Setting Up the Reader
2 Gryphon™ I GM44XX
Setting Up the Reader
Follow the steps below to connect and get your reader up and
communicating with its host.
1. Configure the Base Station starting on this page.
2. Charge the Batteries (see page 11).
3. Link to the Base Station (see page 16).
4. Select the Interface Type (see page 17).
5. Configure the Reader starting on page 29 (optional,
depends on settings needed).
Positioning the Base Station
The base station/charger may be set up in desk application to
hold the reader in two different positions, either a horizontal
or standing position, in order to provide the most comfortable
use depending on needs.
Figure 1. Base Station Positions
Star Models and Frequency
The Gryphon GM4400-xx-433 must be used with
BC40x0-xx-433 base station models.
The Gryphon GM4401-xx-910 must be used with
BC40x1-xx-910 base station models.
