LED and Beeper Indications
Quick Reference Guide 29
ROM Failure
There is an error in
the reader's soft-
ware/programming
Flashes
Reader sounds one
error beep at high-
est volume.
Limited
Scanning Label
Read
Indicates that a
host connection is
not established.
N/A
Reader 'chirps' six
times at the high-
est frequency and
current volume.
Reader Active
Mode
The reader is active
and ready to scan.
The LED is lit
steadily
a
N/A
Reader
Disabled
The reader has been
disabled by the
host.
The LED blinks
continuously
N/A
Green Spot
a
flashes
momentarily
Upon successful
read of a label, the
software shall turn
the green spot on
for the time speci-
fied by the config-
ured value.
N/A N/A
Image Capture
When ready to cap-
ture image
Blue light
flashes 2 times
when updating
N/A
a
Except when in sleep mode or when a Good Read LED Duration other than 00 is selected
Indicator Description LED Beeper
