LED and Beeper Indications
30 Gryphon™ I GD44XX
Programming Mode
-
The following indications ONLY occur
when the reader is in Programming Mode
.
INDICATION DESCRIPTION LED BEEPER
Label Program-
ming Mode Entry
A valid programming
label has been scanned.
LED blinks
continuously
Reader sounds
four low fre-
quency beeps.
Label Program-
ming Mode Rejec-
tion of Label
A label has been
rejected.
N/A
Reader sounds
three times at
lowest fre-
quency and cur-
rent volume.
Label Program-
ming Mode
Acceptance of
Partial Label
In cases where multi-
ple labels must be
scanned to program
one feature, this indica-
tion acknowledges
each portion as it is suc-
cessfully scanned.
N/A
Reader sounds
one short beep at
highest fre-
quency and cur-
rent volume.
Label Program-
ming Mode
Acceptance of
Programming
Configuration option(s)
have been successfully
programmed via labels
and the reader has
exited Programming
Mode.
N/A
Reader sounds
one high fre-
quency beep and
4 low frequency
beeps followed
by reset beeps.
Label Program-
ming Mode Can-
cel Item Entry
Cancel label has been
scanned.
N/A
Reader sounds
two times at low
frequency and
current volume.
