Datalogic IO-Link TL46 User Manual

Teach-in Parameters
Index
(dec)
Parameter Object
Name
Length
Subindex
(o󰀨set)
Value/Range Description Data Type Access* Remark
0x003A (58) TI Select 1 octet 0x00 = SSC1 (default, C/Q pin and DO pin) Selection for Teach-in channel (volatile) UIntegerT R/W
C/Q and DO outputs are antivalent. Teach SSC1
equals to teach SSC2
0x003B (59) TI Result 1 octet
1(0)
2(4)
3(5)
Teach-in State
Flag SP1 TP1
Flag SP2 TP1
See IO-Link Smart Sensor Prole
UIntegerT4
BooleanT
BooleanT
RO
0x003C (60) SSC1 Param
2 octets
2 octets
1(16)
2(0)
220 ..4000
Not used
Switching threshold UIntegerT R/W
Saved in non-volatile memory
*Setting a higher threshold reduces the operating
distance progressively to 0 (output always active)
0x003D (61) SSC1 Cong
1 octet
1 octet
1(24)
2(16)
0x00: High Active
0x01: Low Active (default)
0x01: Single Point (default)
C/Q pin conguration
UIntegerT
UIntegerT
R/W
Saved in non-volatile memory
*In Color Mode (WH model only):
Subindex 1
0x00: NC (default)
0x01: NO
2 octets 3(0)
0 ..2 Hysteresis
0 = low
1 = medium
2 = high
UIntegerT
0x003E (62) SSC2 Param
2 octets
2 octets
1(16)
2(0)
220 ..4000
Not used
Switching threshold UIntegerT R/W
Saved in non-volatile memory
*Setting a higher threshold reduces the operating
distance progressively to 0 (output always active)
0x003F (63) SSC2 Cong
1 octet
1 octet
1(24)
2(16)
0x00: High Active
0x01: Low Active (default)
0x01: Single Point (default)
DO pin conguration
UIntegerT
UIntegerT
R/W
Saved in non-volatile memory
*In Color Mode (WH model only):
Subindex 1
0x00: NC (default)
0x01: NO
2 octets 3(0)
0 ..2 Hysteresis
0 = low
1 = medium
2 = high
UIntegerT
0x005A (90) Sensitivity selection 1 octet 0 ..9 Sensitivity Sensitivity UIntegerT R/W
Saved in non-volatile memory
*The sensitivity will be set during the next
acquisition.
0x0068 (104) Color Threshold Settings
2 octets
2 octets
2 octets
1(32)
2(16)
3(0)
220..4000 (2000 default)
220..4000 (2000 default)
220..4000 (2000 default)
Red Emission Threshold Value
Green Emission Threshold Value
Blue Emission Threshold Value
UIntegerT
UIntegerT
UIntegerT
R/W
Saved in non-volatile memory
*COLOR mode, WH model only
0x0069 (105) Tolerance 1 octet 0..9 (5 default) Tolerance in Color Mode (WH model only) UIntegerT R/W Saved in non-volatile memory
*RO = read only, WO = write only, R/W = read/write
