Installing DL.CODE
1. On the PC that will be used for configuration, (running Windows 7, 8, or 10), download the DL.CODE mini-DVD
.zip file. Extract the files maintaining the folder structure and run the start.hta file to access the installation pop-
up. Click on the Install DL.CODE link to run the installation program and follow the installation procedure.
2. When the installation is complete the DL.CODE entry is created in the Start>Programs bar under “Datalogic” as
well as a desktop icon. Double-click the desktop icon to run it.
3. Follow the Matrix 120 Reference Manual to configure:
Image lighting and code definition (Automatic or Advanced Setup)
Reading Phase and Communication Channel Selection
Data Collection Type
Data Formatting
Digital Output(s)
TECHNICAL FEATURES
