Technical Specifications
Quick Reference Guide 21
Performance Characteristics
Light Source Laser
PD9330 PD9330-AR
Roll (Tilt) Tolerance ± 35° ± 10°
Pitch Tolerance ± 40° ± 60°
Skew (Yaw) Toler-
ance
± 65° ± 65°
Print Contrast Mini-
mum
25% minimum reflectance
Maximum
Resolution
3 mils 7.5 mils
Scan Rate
104 (± 12) scans/
sec
35 (± 5) scans/
sec
Scan Angle 47° max 13.5° ± 0.7°
Depth of Field (Typical)
Symbology
Code 39
PD9330
5 mils 1.5 - 28 cm / 0.6 - 11”
7.5 mils 1.5 - 42 cm / 0.6 - 16.5’
10 mils 2 - 50 cm / 0.8 - 19.7’
20 mils 2 - 110 cm / 0.8 - 43.3’
40 mils 2 - 160 cm / 0.8 - 63’
EAN 13 2.5 - 65 cm / 1 - 25.6”
Symbology Code 39 PD9330-AR
7.5 mils 9 - 50 cm / 3.5 - 19.7”
10 mils 14 - 85 cm / 5.5 - 33.5"
15 mils 15 - 155 cm / 5.9 - 61"
20 mils 15 - 220 cm / 5.9 - 86.6"
40 mils 20 - 340 cm / 7.9 - 133.9"
55 mils 25 - 420 cm / 9.8 - 165.4"
Reflective Label Code 39
70 mils Up to 9 m / 29 ft
100 mils Up to 11.5 m / 37 ft
Note: the reading performances may change with different symbologies.
