Technical Specifications
Quick Reference Guide 19
Performance Characteristics
Light Source Green LED
Roll (Tilt) Tolerance ± 45°
Pitch Tolerance ± 75°
Skew (Yaw) Toler-
ance
± 70°
Print Contrast Mini-
mum
15% minimum reflectance
Maximum
Resolution
2.5 mils
Depth of Field (Typical)
Symbology: Code 39
5 mils 3 - 32 cm / 1.2 - 12.6”
7.5 mils 2 - 48 cm / 0.8 - 18.9”
10 mils 2 - 66 cm / 0.8 - 26”
20 mils 3 - 110 cm / 1.2- 43.3”
40 mils 3 - 230 cm / 1.2- 90.6”
EAN 13 2 - 61 cm / 0.8- 24”
Note: the reading performances may change with dif-
ferent symbologies.
