ENTER/EXIT PROGRAMMING MODE DISPLAY AND KEYBOARD FEATURES
234
POWERSCAN™ PD/PM96XX
DEFINE STRINGS
Configure string 1-5.
To configure this feature, scan the ENTER/EXIT PROGRAMMING MODE bar code at the
top of the page, then the bar code for the String you want to set. Define the label string
by scanning 32 digits from the Alphanumeric characters in
Appendix D, Keypad.
The digits must be the hexadecimal ASCII representation of the desired characters; if
less than the expected string of 16 characters are selected, scan the ENTER/EXIT bar
code to terminate the string.
End by scanning the ENTER/EXIT bar code again.
Set String 1
$CPWEP
$CPWEO
Set String 2
Set String 3
$CPWEA
$CPWEM
Set String 4
Set String 5
$CPWEL
Make a mistake? Scan the CANCEL bar code to abort
and not save the entry string. You can then start
again at the beginning.
CANCEL
To Next Page
