Datalogic QuickScan QD2500 User Manual

Configuring the Interface
QUICK REFERENCE GUIDE 15
★ = default value
Scancode Tables
Refer to QuickScan™ 2500 PRG for information about con-
trol character emulation for keyboard interfaces.
Country Mode
This feature specifies the country/language supported by
the keyboard. Only the following interfaces support ALL
Country Modes.
• USB
Keyboard with alternate key encoding
• USB
Keyboard with standard key encoding
• A
T, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95
w/Std Key Encoding
• K
eyboard Wedge for IBM AT PS2 with standard key
encoding but without external keyboard
• A
T, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95
without Alternate Key
• K
eyboard Wedge for IBM AT PS2 without alternate
key encoding but without external keyboard
All other interfaces support ONLY the
following Country
Modes: U.S., Belgium, United Kingdom, France, Germany,
Italy, Spain, Sweden.
KEYBOARD (CONTINUED)
★ Select USB Keyboard
(USB Keyboard with standard key encoding)
Select USB Alternate Keyboard
(
USB Keyboard with alternate key encoding)

Datalogic QuickScan QD2500 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Linear (1D) barcodes supported	GS1 DataBar
2D (matrix & stacked) barcodes supported	Han Xin, Aztec Code, Data Matrix, QR Code, Micro QR Code
Input voltage	5 V
Power source type	DC, USB
Standard interfaces	Keyboard wedge, RS-232, USB
Connectivity technology	Wired
Cables included	USB Type-C
Keys quantity	1 keys
Product color	Black
LED indicators	Yes
Protection features	Shock resistant, Water resistant
Image formats supported	BMP, JPEG, TIFF
International Protection (IP) code	IP52
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	68 mm
Width	148 mm
Height	126 mm
Weight	145 g
