LED and Beeper Indications
24 QuickScan™ QD2430
Programming Mode
The following indications ONLY occur when the reader is in
Programming Mode
.
Limited Scanning
Label Read
Indicates that a host
connection is not
established.
N/A
Reader 'chirps' six
times at the highest
frequency and current
volume.
Reader Active Mode
The reader is active and
ready to scan.
The LED is lit steadily
a
N/A
Reader
Disabled
The reader has been
disabled by the host.
The LED blinks contin-
uously
N/A
Green Spot
a
flashes
momentarily
Upon successful read of
a label, the software
shall turn the green
spot on for the time
specified by the config-
ured value.
N/A N/A
a
Except when in sleep mode or when a Good Read LED Duration other than 00 is selected
Indicator Description LED Beeper
Indicator Description LED Beeper
Label Programming
Mode Entry
A valid programming label
has been scanned.
LED blinks contin-
uously
Reader sounds four
low frequency beeps.
Label Programming
Mode Rejection of
Label
A label has been rejected. N/A
Reader sounds three
times at lowest fre-
quency and current
volume.
Label Programming
Mode Acceptance of
Partial Label
In cases where multiple
labels must be scanned to
program one feature, this
indication acknowledges
each portion as it is suc-
cessfully scanned.
N/A
Reader sounds one
short beep at highest
frequency and cur-
rent volume.
Indicator Description LED Beeper
