Error Codes
Quick Reference Guide 25
Error Codes
Upon startup, if the reader sounds a long tone, this means the
reader has not passed its automatic Selftest and has entered
FRU (Field Replaceable Unit) isolation mode. If the reader is
reset, the sequence will be repeated. Press and release the
trigger to hear the FRU indication code.
The following table describes the LED flashes/beep codes
associated with an error found.
Label Programming
Mode Acceptance of
Programming
Configuration option(s)
have been successfully pro-
grammed via labels and
the reader has exited Pro-
gramming Mode.
N/A
Reader sounds one
high frequency beep
and 4 low frequency
beeps followed by
reset beeps.
Label Programming
Mode Cancel Item
Entry
Cancel label has been
scanned.
N/A
Reader sounds two
times at low fre-
quency and current
volume.
Number
of LED
Flashes/
Beeps
Error Corrective Action
1 Configuration
Contact Helpdesk for assis-
tance
2Interface PCB
6 Digital PCB
11 Imager
Indicator Description LED Beeper
