Rhino™ 10 Installation Manual
5. Gently insert the SD card into the Rhino™ 10. Push the SD card into the slot until it latches in place.
6. Replace the top cover, and attach it with the four screws you removed in Step 2.
7. Lightly tighten with even torque on all four screws.
SD Card Slot
SD Card Slot
Location
Figure 15 – Installing th
e SD Card
Cleaning the Screen
To keep the Rhino™ 10 in good working order, you may need to clean the screen whenever necessary depending on
the environment in which you use the computer.
Use a soft lint-free cloth or paper towel
The cloth may be used dry or lightly damped with a mild cleaner or Ethanol.
Suitable cleaning products are commercially available pre-packaged for use; one example of such a prod-
uct is Klear Screen™, or off the shelf products such as Glass Plus® Glass and Surface Cleaner.
Be sure the cloth is only lightly damped, not wet. Never apply cleaner directly to touch panel surface.
Wipe dry
Never apply cleaner directly to touch panel surface!
Never use acidic or alkaline cleaners, products that contain Ammonia, Phosphates, or Ethylene Glycol, or
organic cleaners such as paint thinner, acetone, tolulene, xylene, propyl or isopropyl alcohol, or kerosene.
Products containing less than 4% Isopropyl Alcohol are acceptable if all excess cleaner is removed.
Contacting Product Support
If you cannot find the answer to your problem in this manual, you can visit the Datalogic Customer Service site at
www.mobile.datalogic.com to review technical information or to request technical support. If you still need help after
visiting the web site, you may need to call Product Support. Before you call Datalogic Product Support, make sure you
have the following information ready:
Model number and Serial number of your unit
Keypad serial number
Scanner Model Number (and serial # if a Datalogic scanner)
15
