118 A-Class
Media & Ribbon
Media Types: Wound-out labels only and tag stock; roll-fed, die-cut,
notched, reflective, continuous, and fan-fold. Flat
printable side, with no more than .0007 in. (.018 mm)
protrusions on the opposite side (see below).
Ribbon Types:
‘Coated Side In’ or ‘Coated Side Out’.
A-4xxx models: 1 - 4.65 inches (25 – 118 mm) Ribbon Width Range*:
A-6xxx models: 2 - 6.7 inches (51 – 170 mm)
*The ribbon width should slightly exceed the label width (and
backing material).
Ribbon Length: 1968 feet (600 meters)
Ribbon Core Size:
1.01 inches .006 inches (25.6 mm .2 mm) inner
diameter, and core not to protrude beyond the ribbon
edge.
Media Dimensions: Reference the drawing and table below:
E
C
K
A
D
F
F
G
B
I
J
Side View Top View Back View
