Datamax A-Class A-4310 - Print Resolutions and Widths; Speed Ranges; Appendix B

A-Class 127
Appendix B
Print Resolutions and Widths
Print Resolutions and Widths
Maximum Print Width
Model Resolution
Inches Millimeters
Default
Setting
A-4212
203 dots/inch
(8 dots/mm)
4.10 104 4.10
A-4310
300 dots/inch
(11.8 dots/mm)
4.16 105.7 4.16
A-4408
406 dots/inch
(16 dots/mm)
4.10 104 4.10
A-4606
600 dots/inch
(23.6 dots/mm)
4.16 105.6 4.16
A-6212
203 dots/inch
(8 dots/mm)
6.62 168.1 6.62
A-6310
300 dots/inch
(11.8 dots/mm)
6.40 162.6 6.40
Speed Ranges
Speed Ranges and Defaults
Range Default Setting
Model &
Function
IPS MMPS IPS MMPS
A-4212: Print 2-12 51 – 305 8.0 203
Feed 2-12 51 – 305 8.0 203
Reverse 2-5 51 – 127 4.0 102
Slew 2-16 51 – 406 8.0 203
A-4310: Print 2-10 51 – 254 8.0 203
Feed 2-12 51 – 305 8.0 203
Reverse 2-5 51 – 127 4.0 102
Slew 2-16 51 – 406 8.0 203
