Datamax A-Class A-4310 User Manual

A-Class 81
Step Action Displayed Message Comment
M
Complete a table (see
example below) using
three new measurements,
as follows:
(A) Raise the printhead
assembly. Place the
label (attached to
liner) in the Media
Sensor then lower and
latch the Head Lift
Lever. Record the
sensor reading as P.
(B) Raise the printhead
assembly. Place the
liner, notch, or mark
in the Media Sensor
then lower and latch
the Head Lift Lever.
Record the sensor
reading as G (or M).
(C) Raise the printhead
assembly. Remove all
media from the Media
Sensor then lower and
latch the Head Lift
Lever. Record the
sensor reading as E.
GAIN TRAN
*18 (0 – 31)
<yyy>
- or, for reflective media:
GAIN REFL
*18 (0 – 31)
<yyy>
Where ‘yyy’ represents the
current sensor reading.
; The re-sampled values
may differ from those
previously noted. This
is normal; do not
readjust the Media
Sensor.
N
Press the ESC Key and
then the DOWN ARROW
Key. Press the ENTER Key.
SENSOR LEVELS
The sensor readings must
now be entered into the
printer.
Selected Gain Table
Gain Number P (Paper) G (Gap) or M (Mark) E (Empty)
18 173 42 9
(continued)
