SUPPORTED FORMATS 34
10. SUPPORTED FORMATS
VIDEO CAPTURE FORMATS
HDMI INPUT
The HDMI input can capture signals within the HDMI 1.4 bandwidth specication with a maximum
rate of 297 Mpixels/s. The maximum capture resolution is 4096 × 2160p at 30 Hz. HDMI audio
capture is not supported by WATCHOUT.
SDI INPUT
WATCHOUT can capture both interlaced and progressive formats. SDI audio capture is not supported
by WATCHOUT.
SDI INPUT CAPTURE FORMATS (MODELS A, B)
The following SDI interfaces are supported.
SDI INPUT CAPTURE FORMATS (MODEL C)
RESOLUTION FRAMES PER SECOND SINGLE LINK
PAL – – – – – – 50 – –
NTSC – – – – – – – 59.94 –
720p 23.98 24 25 29.7 30 – 50 59.94 60
1080i – – – – – – 50 59.94 60
1080p 23.98 24 25 29.7 30 – 50 59.94 60
DCI 2K 23.98 24 25 29.7 30 48 50 59.94 60
2160i – – – – – – 50 59.94 60
2160p 23.98 24 25 29.7 30 – 50 59.94 60
DCI 4K 23.98 24 25 29.7 30 48 50 59.94 60
RESOLUTION FRAMES PER SECOND
PAL – – – – – – 50 – –
NTSC – – – – – – – 59.94 –
720p 23.98 24 25 29.7 30 – 50 59.94 60
1080i – – – – – – 50 59.94 60
1080p 23.98 24 25 29.7 30 – 50 59.94 60
DCI 2K 23.98 24 25 29.7 30 48 50 59.94 60
VIDEO INTERFACE
SDI COMPLIANCE
SD-SDI
SMPTE 259M
HD-SDI
SMPTE 292M
3G-SDI Level A
SMPTE 424M, SMPTE 425-1
3G-SDI Level B-DS
SMPTE 424M, SMPTE 425-1
