Dataton WATCHPAX 60 - SDI Output Formats (Model C)

SUPPORTED FORMATS 35
The following SDI interfaces are supported (Model C):
VIDEO INTERFACE
SDI COMPLIANCE
SD-SDI
SMPTE 259M
HD-SDI
SMPTE 292M
3G-SDI Level A
SMPTE 424M, SMPTE 425-1
3G-SDI Level B-DS
SMPTE 424M, SMPTE 425-1
6G-SDI
SMPTE 2081-10
12G-SDI
SMPTE 2082-10
VIDEO PLAYOUT FORMATS
SDI OUTPUT FORMATS (MODEL C)
NOTE: Quad-Link Quadrant mode divides a UHD image into four HD quadrants or a DCI 4K image
into four DCI 2K Quadrants. This will create four independent HD-SDI or 3G-SDI Level A streams
depending on framerate.
The following SDI interfaces are supported:
RESOLUTION FRAMES PER SECOND SINGLE LINK
720p 23.98 24 25 29.7 30 – 50 59.94 60
1080p 23.98 24 25 29.7 30 – 50 59.94 60
DCI 2K 23.98 24 25 29.7 30 48 50 59.94 60
2160p 23.98 24 25 29.7 30 – 50 59.94 60
DCI 4K 23.98 24 25 29.7 30 48 50 59.94 60
RESOLUTION FRAMES PER SECOND DUAL LINK
1080p – – – – – – 50 59.94 60
DCI 2K – – – – – 48 50 59.94 60
2160p 23.98 24 25 29.7 30 – – – –
DCI 4K 23.98 24 25 29.7 30 – – – –
RESOLUTION FRAMES PER SECOND QUAD LINK INTERLEAVED
2160p – – – – – – 50 59.94 60
DCI 4K – – – – – 48 50 59.94 60
RESOLUTION FRAMES PER SECOND QUAD LINK QUADRANT
2160p 23.98 24 25 29.7 30 – 50 59.94 60
DCI 4K 23.98 24 25 29.7 30 48 50 59.94 60
VIDEO INTERFACE
SDI COMPLIANCE
HD-SDI SMPTE 292M
Dual-Link HD-SDI SMPTE 372M
Quad-Link HD-SDI Quadrant SMPTE 292M
3G-SDI Level A SMPTE 424M, SMPTE 425-1
Dual-Link 3G-SDI SMPTE 425-3
Quad-Link 3G-SDI Interleaved SMPTE 425-5
Quad-Link 3G-SDI Quadrant SMPTE 424M
6G-SDI SMPTE 2081-10
12G-SDI SMPTE 2082-10
