SUPPORTED FORMATS 36
TIMECODE INPUT FORMATS
ANALOG AUDIO OUTPUT FORMATS
WATCHPAX 60 can output four channels of balanced analog audio through an VHDCI to XLR break-
out cable.
The XLR connectors on the breakout cable are mapped in WATCHOUT according to the table below.
DIGITAL AUDIO OUTPUT FORMATS
WATCHPAX 60 can output multi-channel (7.1) LPCM audio embedded with DisplayPort and HDMI.
DIGITAL AUDIO OUPUT RATES
44.1 kHz
48 kHz
88.2 kHz
96 kHz
176.4 kHz
192 kHz
FORMAT
TYPE
Film 24 fps
EBU 25 fps
SMPTE 29.97 NDF
SMPTE 30 (“B&W”)
SMPTE 29.97 NDF
ANALOG AUDIO OUPUT RATES
44.1 kHz
48 kHz
88.2 kHz
96 kHz
BREAKOUT CABLE LABELS WATCHOUT
Left In 1 Timecode input
Right In 1 N/A, reserved for future use
Left In 2 N/A, reserved for future use
Right In 2 N/A, reserved for future use
Left Out 1 Output Channel 1
Right Out 1 Output Channel 2
Left Out 2 Output Channel 3
Right Out 2 Output Channel 4
