Davey DynaDrive DD15-35NPT

12
• The
Automatic LED will illuminate bright green indicating that the pump is running
Once the set pressure has been achieved, the DynaDrive will slow the motor speed. If the pressure drops
below set pressure, the motor speed will increase again to maintain pressure. However, if the pressure does
not drop below set pressure, the motor speed will continue to decrease, until it’s off.
The
Automatic LED will flash green to indicate the pump is in standby maintaining pressure, see
figure 6.4.
Figure 6.4
P/N:16115-1 BP/N:16115-1 B
Pset 60
Pact 60
6.2 Manual override
In addition to automated control, DynaDrive can also be run in manual override on, should the need arise.
IMPORTANT: It should be noted that when the pump is manually turned on, the
automated protection built into DynaDrive is overridden. Davey recommends use of the
manual override only when absolutely necessary and only for a short time period.
To switch to manual override on:
• Ensure automated control is turned off. To turn the automated control off, push the
Automatic on /
manual off button.
• The green
Automatic LED will turn off, see figure 6.5;
