Davey DynaDrive DD15-35NPT

16
Figure 6.10
P/N:16115-1 BP/N:16115-1 B
pressure
60 Psi
• If the controls are untouched for ~ 30 seconds, the menu will revert back to normal display;
• To change the set pressure, use the
Menu up button or Menu down button.
Pressure changes are in multiples 5psi.
• Once you’ve reached your new set point, see figure 6.11;
Figure 6.11
P/N:16115-1 BP/N:16115-1 B
pressure
44 psi
• Press Enter button, or Menu button to return to the HOME SCREEN, see figure 6.12;
