7. ADVANCED SETTINGS
7.1 Changing cut-in pressure point
The default cut-in pressure of DynaDrive is 50kPa (7psi) less than set point. This can be changed by:
• Ensure automated control is turned off. To turn the automated control off, push the
Automatic on /
manual off button.
• The green
Automatic LED will turn off, see figure 7.1;
Figure 7.1
P/ N :16115-1 B
Pset 400
Pact 400
• Once the motor has slowed to a stop, press and hold the Menu button and Enter button for ~
5 seconds. The display will change to show your current set pressure, see figure 7.2;
Figure 7.2
P/ N :16115-1 B
pressure
400 kPa
