Davey DynaDrive DD60-10

30
ITEM NOTES DESCRIPTION
QTY
REQ’D PART NO.
10 Stage body - Inner stages As required 13662-2
11 Stage body - Final 1 13663
12 Spacer - Destage 1 13696-1
13 B Washer - Cup As required 13666
14 Clip spring 2 13667
15 Seal - Mechanical 1 400558SP
16 Backplate 1 13660
19 8L pressure tank DD60-10(CE), DD90-11(CE) 1 24008P
20 Fan cowl DD60-10(CE), DD90-11(CE) 1 11150-40M
20 Fan cowl DD60-10NPT, DD90-11NPT 1 11150-40MNPT
21 VSD adaptor DD60-10(CE), DD90-11(CE) 1 16098
21 VSD adaptor DD60-10NPT, DD90-11NPT 1 16098-1
22 Pressure transducer & loom 1 RECH092SP
23 O-ring to suit adaptor VSD 1 402442
24 DynaDrive power module DD60-10(CE), DD90-11(CE) 1 RECH092345SP
24 DynaDrive power module DD60-10NPT, DD90-11NPT 1 TBC
25 DynaDrive control module DD60-10(CE), DD90-11(CE) 1 RECH091SP
25 DynaDrive control module DD60-10NPT, DD90-11NPT 1 TBC
- Slinger - Water 1 13648
