11. TYPICAL (EVERYDAY) START-UP
Note: Once the unit starts there is a short time delay until the cell operates to ensure the filtration
system is primed with water.
• Every time the ChloroMatic Nipper is turned on, the following screen is shown on start-up:
DAVEY
V1.2.1 EU 15L
Figure 11.1
• The display then automatically reverts to the HOME screen:
100% – 07:31 AM
AUTO ON
Figure 11.2
> This screen shows the:
■ current chlorine output setting (ie 100% shown);
■ current time setting;
■ current power status:
AUTO ON: (ie as shown above) indicates the ChloroMatic Nipper is currently operating within the
ON-TIME of either TIMER 1, or TIMER 2;
AUTO: indicates the ChloroMatic Nipper is powered but is within the OFF-TIME of both
TIMER 1, and TIMER 2;
MANUAL ON: indicates the ChloroMatic Nipper is currently operating, having been manually overridden;
OFF: indicates the ChloroMatic Nipper is powered but is not currently operating, having been
manually overridden.
