4
Diagram A
CORRECT OPERATION
WITH A PUMP RUNNING
Diagram B
INCORRECT OPERATION
WITH A PUMP RUNNING
ü
û
• Always check for the latest versions of installation and
operation instructions that support these products.
Simply scan this QR code, or go to: www.bit.ly/nippercm
2. IMPORTANT SAFETY INSTRUCTIONS
• To minimise the risk of gas build-up in the cell housing, you must ensure there is sufcient
water ow through the cell when the unit is on and producing chlorine.
• It is essential that your pool pump circulates sufcient water through the cell housing to
completely ll the cell housing with water during the chlorination process.
• Periodically check the paddle of the safety ow switch to ensure it is free to move back and
forth and that the lock nut is done up hand tight.
Figure 2.1
Figure 2.2
