1. INTRODUCTION
SPECIFICATIONS
(CONT’D)
Analog Filters: 0.2, 2, 20, 200, or 2000 Hz, selectable when
the 3000PLUS meter is configured
Status Indicator Light: Green/Yellow/Red; indicates module
input and communications status (see Section 1.D)
Table 1
Model 5D64 Full-Scale Ranges (Nominal),
with Corresponding Accuracies and
Common-Mode Ranges*
(Accuracy given as % of full scale overall
expected maximum error, following calibration)
Range C-M Range
(VDC, f.s.) Accuracy (V)
0.05 0.04 1
0.075 0.04 1
0.1 0.04 1
0.15 0.04 1
0.2 0.03 1
0.3 0.03 1
0.4 0.03 1
0.5 0.02 1
0.75 0.02 2
1 0.02 2
1.5 0.02 2
2 0.02 2
3 0.02 15
4 0.02 15
5 0.02 15
7.5 0.02 40
10 0.02 40
15 0.02 40
20 0.02 40
30 0.02 40
40 0.02 150
50 0.02 150
75 0.02 150
100 0.02 150
150 0.03 150
* See Table 2 in Appendix B for the “practical” ranges that apply to
the 5D64
RANGE (RNG) setting. Common-mode ranges listed in
the table are given in ±VDC, maximum operating, and apply only
when the 10-VDC excitation provided by the 5D64 is in use.
