Raider Max 175 (single-seat, double-seat): Service Manual EEC Version:2.0 April 2005
30
seal;
b) Disassemble the water pump impeller;
Remove the water pump impeller;
c) Check the water seal and the water seal washer
for damages and wear;
Replace the water seal together with the water
seal washer if necessary;
d) Assemble the water pump shaft and the inner
bearing into the right crankcase;
Lock the bearing with the clip;
e) Assemble the right crankcase cover;
f) Assemble the water pump impeller;
Replace the water pump water seal together
with the impeller water seal if necessary;
