DB ELETTRONICA TELECOMUNICAZIONI S.p.A.
PM 1000 – 1 kW FM Broadcasting Transmitter - USER’S MANUAL
9 /101
Fig. 1.3 – PM1000 TRANSMITTER TOP VIEW
1) Blower 6) Remote control board
2) Output filter 7) Protection board (controls)
3) Output coupler 8) Protection board (panel)
4) AMP300, 300 W amplifier boards
5) Switching power supply board
